技术特征
frame range | h112~160 | power range | 1.8~7.5kw |
| rated voltage | 380v（special voltage customization） | rated frequency | 50hz（special frequency customization） |
| poles | 4、6 | protection degree | ip54 |
| cooling mode | ic411 | insulation class | f |
| operation mode | s1 | installation mode | b3 |
| wiring mode | y/∆ |
fq series high starting torque three-phase asynchronous motor
this series of motors are closed self fan cooled squirrel cage three-phase asynchronous motors. it has extremely high starting torque and good low-frequency operation characteristics. it is especially suitable for occasions with impact load. in this case, it is more energy-saving than ordinary motors. this series of motor is the main motor for water jet loom. it has no junction box and adopts outlet board. it can also be used in occasions similar to the above situation. delta connection is adopted when the motor is started and y connection is adopted during operation.
运行条件
-15°c~ 40°c
环境空气温度
≤90%
(当温度为25°c时)
环境空气月平均最高相对湿度
≤1km
海拔
| model | poles | rated power | current | rated speed | protection degree | insulation class | working system | connection | frequency | rated voltage |
| kw | a | r/min | hz | v | ||||||
| fq112m0-4 | 4 | 1.8 | 4.1 | 1450 | ip54 | f | s1 | y | 50 | 380 |
| fq112m1-4 | 4 | 2.2 | 5.0 | 1390 | ip54 | f | s1 | y | 50 | 380 |
| fq112m2-4 | 4 | 2.6 | 5.9 | 1380 | ip54 | f | s1 | y | 50 | 380 |
| fq112m3-4 | 4 | 2.7 | 6.1 | 1380 | ip54 | f | s1 | y | 50 | 380 |
| fq112m4-4 | 4 | 2.8 | 6.3 | 1380 | ip54 | f | s1 | y | 50 | 380 |
| fq132m0-4 | 4 | 3.0 | 6.9 | 1430 | ip54 | f | s1 | y | 50 | 380 |
| fq132m1-4 | 4 | 3.5 | 8.0 | 1425 | ip54 | f | s1 | y | 50 | 380 |
| fq132m2-4 | 4 | 3.7 | 8.5 | 1430 | ip54 | f | s1 | y | 50 | 380 |
| fq132m3-4 | 4 | 4.0 | 9.2 | 1430 | ip54 | f | s1 | y | 50 | 380 |
| fq132l1-4 | 4 | 4.5 | 9.8 | 1420 | ip54 | f | s1 | y | 50 | 380 |
| fq132l2-4 | 4 | 5.0 | 10.9 | 1420 | ip54 | f | s1 | y | 50 | 380 |
| fq132l3-4 | 4 | 5.5 | 11.8 | 1415 | ip54 | f | s1 | y | 50 | 380 |
| fq132l4-4 | 4 | 6.5 | 13.9 | 1415 | ip54 | f | s1 | y | 50 | 380 |
| fq132l5-4 | 4 | 7.5 | 17.1 | 1400 | ip54 | f | s1 | y | 50 | 380 |
| fq160l1-6 | 6 | 6.5 | 14.4 | 965 | ip54 | f | s1 | y | 50 | 380 |
| fq160l2-6 | 6 | 7.5 | 16.6 | 965 | ip54 | f | s1 | y | 50 | 380 |
